TFX0515/8
Kod EAN: 0739894644754
Celestion is one of the finest-sounding names in the world of speakers. The speakers of the TF series feature an excellent price-performance ratio and at the same time provide excellent sound characteristics. Thus, they are ideally suited for an appl...
TFX0515/8
Celestion is one of the finest-sounding names in the world of speakers.
The speakers of the TF series feature an excellent price-performance ratio and at the same time provide excellent sound characteristics. Thus, they are ideally suited for an application in high-performance PA speaker systems which provide a powerful sound.
PA coaxial speaker, 150 W, 8 Ω
- 12.7 cm (5") made of extruded steel
- 25 mm (1") with silk dome and ferrite magnet
- Nominal radiation angle of tweeter: 110°
Manufacturer information:
Celestion International Ltd
Claydon Business Park, Great Blakenham,
Ipswich
Suffolk IP6 0NL
United Kingdom
info@celestion.com
Claydon Business Park, Great Blakenham,
Ipswich
Suffolk IP6 0NL
United Kingdom
info@celestion.com
Importer:
MONACOR INTERNATIONAL GmbH & Co. KG
Konsul-Smidt-Str. 68
28217 Bremen
Deutschland
info@monacor.com
Konsul-Smidt-Str. 68
28217 Bremen
Deutschland
info@monacor.com
Parametry
| Impedance (Z) | 8 Ω |
| Transmission technology | cable |
| Frequency range | 80-4,000 Hz (bass) 1,400-20,000 Hz (tweeter) |
| Resonant frequency (fs) | 74 Hz |
| Rec. crossov. frequ. (fmax.) (12 dB/oct.) | 2,200 Hz |
| Power rating (RMS) | 150 W (bass) / 10 W (tweeter) |
| Peak music power output (MAX) | 300 W (bass) / 20 W (tweeter) |
| SPL | 89 dB (bass) / 96 dB (tweeter) |
| Suspension compl. (Cms) | 0.509 mm/N |
| Moving mass (Mms) | 9.073 g |
| Mech. Q factor (Qms) | 8.293 |
| Electr. Q factor (Qes) | 0.503 |
| Total Q factor (Qts) | 0.747 |
| Equivalent volume (Vas) | 6.5 l |
| DC resistance (Re) | 5.77 Ω |
| Force factor (BxL) | 6.96 Tm |
| Voice coil induct. (Le) | 0.363 mH |
| Voice coil diameter | Ø 38 mm (bass) / Ø 25 mm (tweeter) |
| Voice coil winding height | 10.5 mm |
| Voice coil material | copper wire |
| Voice coil former | polyimide |
| Linear excursion (XMAX) | 3.75 mm |
| Eff. cone area (Sd) | 95 cm2 |
| Magnet weight | 0.65 kg |
| Mounting cutout | Ø 116 mm |
| Mounting depth | 72 mm |
| Mounting hole diameter | Ø 140 mm |
| Dimensions | 136 x 151 x 72 mm |
| Width | 136 mm |
| Height | 151 mm |
| Depth | 72 mm |
| Colour | black |
| Admiss. ambient temp. | 0-40 °C |
| Weight | 1.54 kg |
| Packing unit | 1 |
| Type of speaker | 5" |
| Packaging dimensions (W x H x L) | 0.185 x 0.102 x 0.185 m |
| Gross weight | 1.86 kg |
| Net weight | 1.54 kg |
