PA stredobasový reproduktor, 220W Max, 8ohm 10"
RBT-1000
Kod EAN: 4007754226898
Ribbon tweeter for PA and hi-fi, 40 W, 6 Ω Magnetostatic speaker with waveguide Tweeter system from the L-RAY/1000 Fine and brilliant reproduction of the high frequencies For use from 3,000 Hz (hi-fi) or 4,000 Hz (PA) on via 12 dB filter Diecast alum...
132,00 € brutto
(inkl. 20% DPH)
110,00 € netto
RBT-1000
Ribbon tweeter for PA and hi-fi, 40 W, 6 Ω
- Magnetostatic speaker with waveguide
- Tweeter system from the L-RAY/1000
- Fine and brilliant reproduction of the high frequencies
- For use from 3,000 Hz (hi-fi) or 4,000 Hz (PA) on via 12 dB filter
- Diecast aluminium horn front attachment, neodymium magnet
- Vertical or horizontal mounting possible due to square front panel
- Installation into a sealed airtight housing is recommended
Parametry
| Impedance (Z) | 6 Ω |
| Frequency range | fx-22,000 Hz |
| Resonant frequency (fs) | 1.6 kHz |
| Rec. crossov. frequ. (fmax.) (12 dB/oct.) | > 3,000 Hz |
| Power rating (RMS) | 40 W |
| Peak music power output (MAX) | 80 W |
| SPL | 96 dB/W/m |
| DC resistance (Re) | 6 Ω |
| Magnet diameter | magnetostatic speaker |
| Mounting cutout | 89 x 76 mm |
| Mounting depth | 24 mm |
| Hole spacing X-axis | 87 mm |
| Hole spacing Y-axis | 87 mm |
| Dimensions | 104 x 104 x 24 mm |
| Width | 104 mm |
| Height | 104 mm |
| Depth | 24 mm |
| Colour | black |
| Admiss. ambient temp. | 0-40 °C |
| Weight | 0.24 kg |
| Packing unit | 1 |
| Packing dimensions (W x H x L) | 0.12 x 0.035 x 0.12 m |
| Gross weight | 0.263 kg |
| Net weight | 0.237 kg |
