FTR12-4080DL/8

Kod EAN: 0739894633710

PA subwoofer, 700 W, 8 Ω Glass fibre reinforced waterproof impregnated paper cone Optimised double suspension Ventilated magnet arrangement for dynamic heat dissipation Manufacturer information: Celestion International LtdClaydon Business Park,...

víc

Staň se partnerem
Kup teď


FTR12-4080DL/8

PA subwoofer, 700 W, 8 Ω
  • Glass fibre reinforced waterproof impregnated paper cone
  • Optimised double suspension
  • Ventilated magnet arrangement for dynamic heat dissipation
Manufacturer information:
Celestion International Ltd
Claydon Business Park, Great Blakenham,
Ipswich
Suffolk IP6 0NL
United Kingdom
info@celestion.com

Importer:
MONACOR INTERNATIONAL GmbH & Co. KG
Konsul-Smidt-Str. 68
28217 Bremen
Deutschland
info@monacor.com

Parametry

Impedance (Z) 8 Ω
Transmission technology cable
Frequency range 20-300 Hz
Resonant frequency (fs) 28.90 Hz
Power rating (RMS) 700 W
Peak music power output (MAX) 1,400 W
SPL 88 dB/W/m
Suspension compl. (Cms) 0.17 mm/N
Moving mass (Mms) 176.07 g
Mech. Q factor (Qms) 2.466
Electr. Q factor (Qes) 0.345
Total Q factor (Qts) 0.303
Equivalent volume (Vas) 68.6 l
DC resistance (Re) 6.24 Ω
Force factor (BxL) 24.05 Tm
Voice coil induct. (Le) 2.07 mH
Voice coil diameter Ø 100 mm
Voice coil winding height 32 mm
Voice coil material copper wire
Voice coil former aluminium
Linear excursion (XMAX) ± 13.6 mm
Eff. cone area (Sd) 550.93 cm2
Magnet weight 3.6 kg
Mounting cutout Ø 282 mm
Mounting depth 169 mm
Mounting hole diameter Ø 291-301 mm
Dimensions Ø 313 mm x 169 mm
Outside diameter Ø 313 mm
Width Ø 313 mm
Height Ø 313 mm
Depth 169 mm
Colour black
Admiss. ambient temp. 0-40 °C
Weight 10.2 kg
Packing unit 1
Type of speaker 12"
Packaging dimensions (W x H x L) 0.356 x 0.2 x 0.356 m
Gross weight 11.5 kg
Net weight 10 kg

Na stáhnutí

Produktová karta FTR12-4080DL/8 Technický produktový list konformitaetserklaerung-ce konformitaetserklaerung-ukca
