CDX1-1747/8
Kod EAN: 0739894584852
PA horn driver, 60 W, 8 Ω High-quality 25 mm (1") compression driver with 44 mm (1.75") voice coil and ferrite magnet Modern development with Finite Element Analysis (FEA) Standard 2-hole and 3-hole screw mounting Wideband and highly linear frequency...
CDX1-1747/8
PA horn driver, 60 W, 8 Ω
- High-quality 25 mm (1") compression driver with 44 mm (1.75") voice coil and ferrite magnet
- Modern development with Finite Element Analysis (FEA)
- Standard 2-hole and 3-hole screw mounting
- Wideband and highly linear frequency response up to 20,000 Hz
- Very high sound pressure with minimum distortion
Manufacturer information:
Celestion International Ltd
Claydon Business Park, Great Blakenham,
Ipswich
Suffolk IP6 0NL
United Kingdom
info@celestion.com
Claydon Business Park, Great Blakenham,
Ipswich
Suffolk IP6 0NL
United Kingdom
info@celestion.com
Parametry
| Impedance (Z) | 8 Ω |
| Transmission technology | cable |
| Frequency range | 1,000-20,000 Hz |
| Rec. crossov. frequ. (fmax.) (12 dB/oct.) | 1,600 Hz |
| Power rating (RMS) | 60 W |
| Peak music power output (MAX) | 120 W |
| SPL | 110 dB/W/m |
| Voice coil diameter | Ø 44 mm |
| Voice coil material | flat copper-coated aluminium wire |
| Outlet | 25 mm |
| Mounting cutout | dep. on horn |
| Mounting depth | dep. on horn |
| Mounting hole diameter | Ø 76 mm (2 x M6), Ø 57.2 mm (3 x M6) |
| Dimensions | Ø 120 mm x 53 mm |
| Outside diameter | Ø 120 mm |
| Width | Ø 120 mm |
| Height | Ø 120 mm |
| Depth | 53 mm |
| Colour | black |
| Admiss. ambient temp. | 0-40 °C |
| Weight | 1.96 kg |
| Packing unit | 1 |
| Type of speaker | 1" |
| Packaging dimensions (W x H x L) | 0.135 x 0.07 x 0.178 m |
| Gross weight | 2.06 kg |
| Net weight | 1.96 kg |
