SP-10/250PRO
Kod EAN: 4007754232332
PA basový reproduktor, subwoofer, 250 W, 8 Ω 25 cm (10") basový reproduktor a subwoofer s vysokým výkonom Teplu odolná cievka a vetraný systém pohonu Extra dlhá exkurzia pre hlbokú reprodukciu basov pri vysokej hlasitosti Progresívne upínanie membrány...
142,00 € brutto
(inkl. 20% DPH)
118,33 € netto
SP-10/250PRO
PA basový reproduktor, subwoofer, 250 W, 8 Ω
- 25 cm (10") basový reproduktor a subwoofer s vysokým výkonom
- Teplu odolná cievka a vetraný systém pohonu
- Extra dlhá exkurzia pre hlbokú reprodukciu basov pri vysokej hlasitosti
- Progresívne upínanie membrány pre vysokú prevádzkovú bezpečnosť
- Stabilný kôš z liateho hliníka
- Ideálny pre kompaktné subwoofery a 2-pásmové systémy s krížovou frekvenciou približne 1,500 Hz na výškový reproduktor
HOBBY HiFi 03/2014"A bass driver of particularly long excursion and high level stability for compact cabinets of about 35 litres (e.g. in the speaker building concept HiFi-PA 10/2). The HiFi-PA 10/2 impressed with a breathtaking power in the audio room. ... tremendous level reserves ... incredibly filigree."
HOBBY HiFi 02/2014"A bass driver of particularly long excursion and high level stability for more compact reflex cabinets of about 35 to 40 litres."
Klang+Ton 03/2013"Universal Basový reproduktor for powerful applications. Skilfully selected TSP ensure high subwoofer levels from compact cabinets."
Parametry
| Impedance (Z) | 8 Ω |
| Transmission technology | cable |
| Frequency range | f3-2,000 Hz |
| Resonant frequency (fs) | 47 Hz |
| Power rating (RMS) | 250 W |
| Peak music power output (MAX) | 500 W |
| SPL | 94 dB/W/m |
| Suspension compl. (Cms) | 0.20 mm/N |
| Moving mass (Mms) | 51 g |
| Mech. Q factor (Qms) | 6.16 |
| Electr. Q factor (Qes) | 0.35 |
| Total Q factor (Qts) | 0.33 |
| Equivalent volume (Vas) | 40.7 l |
| DC resistance (Re) | 7.1 Ω |
| Force factor (BxL) | 18.30 Tm |
| Voice coil induct. (Le) | 0.83 mH |
| Voice coil diameter | Ø 75 mm |
| Voice coil former | Kapton |
| Linear excursion (XMAX) | ± 7 mm |
| Eff. cone area (Sd) | 380 cm2 |
| Magnet weight | 2 kg |
| Magnet diameter | Ø 169 mm |
| Mounting cutout | Ø 228 mm |
| Mounting depth | 111 mm |
| Dimensions | Ø 261 mm x 121 mm |
| Outside diameter | Ø 261 mm |
| Width | Ø 261 mm |
| Height | Ø 261 mm |
| Depth | 121 mm |
| Colour | black |
| Admiss. ambient temp. | 0-40 °C |
| Weight | 5 kg |
| Packing unit | 1 |
| Type of speaker | 10" |
| Packaging dimensions (W x H x L) | 0.28 x 0.17 x 0.28 m |
| Gross weight | 5.59 kg |
| Net weight | 5 kg |
