Mini laser efekt
PA-812DAP
Kod EAN: 4007754276688
Mono class D PA mixing amplifier, with integrated MP3 player, FM/DAB+ tuner and Bluetooth. 1 x 120 W Class D concept with high efficiency to cut energy costs Silent operation due to fanless cooling concept Bluetooth version 4.2 MP3 player with USB/...
487,00 € brutto
(inkl. 20% DPH)
405,83 € netto
PA-812DAP
Mono class D PA mixing amplifier,
with integrated MP3 player, FM/DAB+ tuner and Bluetooth.
- 1 x 120 W
- Class D concept with high efficiency to cut energy costs
- Silent operation due to fanless cooling concept
- Bluetooth version 4.2
- MP3 player with USB/SD interface, FM/DAB+ radio, LED display, infrared remote control
- Reception of interference-free digital radio (DAB+)
- 1 balanced XLR microphone input with 48 V phantom power and priority selection for announcements
- 2 unbalanced inputs, switchable mic/line
- 2 unbalanced line inputs
- 1 TEL input
- 1 Music-On-Hold output (MOH)
- Speaker outputs via screw contacts
- Mute function via screw contact
- 1 amp input
- 1 preamp output
- Input level control and output level control
- 2-way tone control for the output
- LEDs for indicating operation, clipping, protect and signal level
Parametry
| Peak output power | 120 W |
| Power rating | 120 W |
| Power rating at 4 Ω | 120 W |
| Power rating at 8 Ω | 120 W |
| Power rating at 16 Ω | 120 W |
| Power rating at 100 V | 120 W |
| Power rating at 70 V | 120 W |
| Channels | 1 |
| Zones | 1 |
| Inputs | 4.5 mV/600 Ω (channel 1), 4.5 mV/120 mV (channels 2-3), 60 mV (channels 4-5) 90 mV (tel.) |
| Frequency range | 60-15,000 Hz |
| Equalizer bass | ± 10 dB |
| Equalizer treble | ± 10 dB |
| S/N ratio | 72 dB (mic, channels 1-3) 85 dB (line, channels 2-5) |
| THD | < 0.5% |
| Phantom power | 48 V |
| Power supply | ˜ 230 V/50 Hz/250 VA DC 24 V/8.4 A |
| Mains voltage | ~ 230 V |
| Mains frequency | 50 Hz |
| Power consumption, operation | 250 VA |
| Operating voltage (possible alternative) | DC 24 V |
| Power supply (possible alternative) | 8.4 A |
| Admiss. ambient temp. | 0-40 °C |
| Width | 320 mm |
| Height | 95 mm |
| Depth | 245 mm |
| Weight | 4.5 kg |
| Connections | 1 x XLR (channel 1), 2 x 6.3 mm jack (channels 2-3) 2 x RCA L/R (channels 4-5), 1 x RCA (amp in), 1 x RCA (preamp out), 1 x F jack (FM/DAB+), screw contacts (tel. input), screw contacts (MOH), screw contacts ( DC 24 V), screw contacts (mute), screw contacts (speakers) |
| Packaging dimensions (W x H x L) | 0.395 x 0.16 x 0.305 m |
| Gross weight | 5.2 kg |
| Net weight | 4.51 kg |
