CF1540HD/8

Kod EAN: 0739894599054

PA bass speaker, 1,200 W,8 Ω Glass fibre reinforced paper cone with weatherproof impregnation Two demodulation rings Optimised double suspension Balanced ventilation for enhanced cooling Manufacturer information: Celestion International LtdClay...

víc

Staň se partnerem
Kup teď


CF1540HD/8

PA bass speaker, 1,200 W,8 Ω
  • Glass fibre reinforced paper cone with weatherproof impregnation
  • Two demodulation rings
  • Optimised double suspension
  • Balanced ventilation for enhanced cooling
Manufacturer information:
Celestion International Ltd
Claydon Business Park, Great Blakenham,
Ipswich
Suffolk IP6 0NL
United Kingdom
info@celestion.com

Importer:
MONACOR INTERNATIONAL GmbH & Co. KG
Konsul-Smidt-Str. 68
28217 Bremen
Deutschland
info@monacor.com

Parametry

Impedance (Z) 8 Ω
Transmission technology cable
Frequency range 35-2,000 Hz
Resonant frequency (fs) 40.8 Hz
Power rating (RMS) 1,200 W
Peak music power output (MAX) 2,400 W
SPL 97 dB/W/m
Suspension compl. (Cms) 0.11 mm/N
Moving mass (Mms) 145.53 g
Mech. Q factor (Qms) 5.591
Electr. Q factor (Qes) 0.323
Total Q factor (Qts) 0.305
Equivalent volume (Vas) 108.3 l
DC resistance (Re) 5.15 Ω
Force factor (BxL) 24.40 Tm
Voice coil induct. (Le) 1.22 mH
Voice coil diameter Ø 100 mm
Voice coil winding height 25 mm
Voice coil material copper wire
Voice coil former glass fibre
Linear excursion (XMAX) ± 10.5 mm
Eff. cone area (Sd) 855.3 cm2
Magnet weight 3.18 kg
Mounting cutout Ø 354 mm
Mounting depth 184 mm
Mounting hole diameter Ø 367-374 mm
Dimensions Ø 393 mm x 184 mm
Outside diameter Ø 393 mm
Width Ø 393 mm
Height Ø 393 mm
Depth 184 mm
Colour black
Admiss. ambient temp. 0-40 °C
Weight 11.2 kg
Packing unit 1
Type of speaker 15"
Packaging dimensions (W x H x L) 0.435 x 0.23 x 0.435 m
Gross weight 12.6 kg
Net weight 11.2 kg

Na stáhnutí

Produktová karta CF1540HD/8 Technický produktový list konformitaetserklaerung-ce konformitaetserklaerung-ukca
