CDX1-1730/8

Kod EAN: 0739894548540

PA horn driver, 40 W, 8 Ω High-quality 25 mm (1") compression driver with 44 mm (1.75") voice coil and neodymium magnet One-piece PETP film cone and surround Sound castle cone arrangement Recommended crossover frequency: 2,200 Hz (12 dB/oct.) 25 mm s...

víc

162,00 € brutto

(inkl. 20% DPH)
135,00 € netto

Staň se partnerem
Kup teď


CDX1-1730/8

PA horn driver, 40 W, 8 Ω
  • High-quality 25 mm (1") compression driver with 44 mm (1.75") voice coil and neodymium magnet
  • One-piece PETP film cone and surround
  • Sound castle cone arrangement
  • Recommended crossover frequency: 2,200 Hz (12 dB/oct.)
  • 25 mm sound outlet

Parametry

Impedance (Z) 8 Ω
Transmission technology cable
Frequency range 1,200-20,000 Hz
Rec. crossov. frequ. (fmax.) (12 dB/oct.) 2,200 Hz
Power rating (RMS) 40 W
Peak music power output (MAX) 80 W
SPL 110 dB/W/m
Radiation angle dep. on horn
Voice coil diameter Ø 44 mm
Voice coil material flat copper-coated aluminium wire
Outlet Ø 2 mm
Mounting cutout dep. on horn
Mounting depth dep. on horn
Mounting hole diameter Ø 76 mm (4x M6)
Dimensions Ø 88.5 mm x 55 mm
Outside diameter Ø 88.5 mm
Width Ø 88.5 mm
Depth 55 mm
Colour black
Admiss. ambient temp. 0-40 °C
Weight 0.64 kg
Packing unit 1
Type of speaker 1"
Packing dimensions (W x H x L) 0.135 x 0.075 x 0.105 m
Gross weight 0.778 kg
Net weight 0.637 kg

Na stáhnutí

Produktová karta CDX1-1730/8 Technický produktový list konformitaetserklaerung-ce konformitaetserklaerung-ukca
